INFO MOTOR
| Make Model | : | Triumph Scrambler 400X |
|---|---|---|
| Year | : | 2024 |
| Engine | : | Four stroke, DOHC, single cylinder, 4 valves |
| Capacity | : | 398 cc / 24.3 cu-in |
| Bore x Stroke | : | 89.0 x 64.0mm |
| Cooling System | : | Liquid cooled |
| Compression Ratio | : | 12.1:1 |
| Induction | : | Bosch ride-by-wire EFI |
| Emission | : | Euro 5 |
| Starting | : | Electric |
| Max Power | : | 29.4 kW / 40hp @ 8000 rpm |
| Max Torque | : | 38 Nm / 28 ft-lbs @ 6500 rpm |
| Clutch | : | Wet multiplate with assist and slip functions |
| Transmission | : | 6-Speed |
| Final Drive | : | X-ring chain |
| Frame | : | Hybrid spine/perimeter, tubular steel, bolt-on rear subframe |
| Swingarm | : | Twin-sided, cast aluminium alloy |
| Front Suspension | : | 43mm Showa Big Piston, non-adjustable inverted fork |
| Front Wheel Travel | : | 150 mm / 5.9 in |
| Rear Suspension | : | Gas monoshock RSU with external reservoir and pre-load adjustment. |
| Rear Wheel Travel | : | 150 mm / 5.9 in |
| Front Brakes | : | Single 320 mm fixed disc with radially mounted 4-piston caliper |
| Rear Brakes | : | Single 230 mm disc with floating caliper |
| ABS | : | Bosch dual channel |
| Wheels Front | : | 19 x 2.5 in with 10-spoke cast aluminium alloy rims |
| Wheels Rear | : | 17 x 3.5 in with 10-spoke cast aluminium alloy rims |
| Front Tyre | : | 100/970 x R19 |
| Rear Tyre | : | 1450/80 x R17 |
| Rake | : | 23.2┬░ |
| Trail | : | 108 mm / 4.25 in |
| Dimensions | : | Length: 2117 mm / 83.3 in Width: 825 mm / 32.5 in Height: 1190 mm / 46.8 in |
| Wheelbase | : | 1418 mm / 55.8 in |
| Seat Height | : | 835 mm / 32.9 in |
| Wet Weight | : | 179 kg / 394.6 lbs |
| Fuel Capacity | : | 13 Litres / 3.43 US gal |
| Instruments | : | Analogue speedometer with integrated multi-function LCD screen |
