INFO MOTOR
| Make Model | : | Triumph Tiger 900 Rally Arag├│n Edition |
|---|---|---|
| Year | : | 2024 |
| Engine | : | Four stroke, transverse three cylinder, DOHC, 4 valve per cylinder. |
| Capacity | : | 888 cc / 54.1 cu-in |
| Bore x Stroke | : | 78 x 61.9 mm |
| Cooling System | : | Liquid cooled |
| Compression Ratio | : | 11.27:1 |
| Exhaust | : | Stainless steel 3 into 1 header system, side mounted stainless steel silencer |
| Emission | : | Euro 5 |
| Lubrication | : | Wet sump |
| Induction | : | Multipoint sequential electronic fuel injection |
| Ignition | : | Digital CDI |
| Starting | : | Electric |
| Max Power | : | 70 kW / 93.9 hp @ 8750 rpm |
| Max Torque | : | 87 Nm / 64.1 lb-ft @ 7250 rpm |
| Clutch | : | Wet, multi-plate |
| Transmission | : | 6 Speed |
| Final Drive | : | O-ring chain |
| Frame | : | Tubular steel frame, bolt on sub frame |
| Swingarm | : | Twin-sided, cast aluminium alloy |
| Front Suspension | : | Showa 45mm upside down forks, manual preload, rebound damping and compression damping adjustment |
| Front Wheel Travel | : | 240 mm / 9.4 in |
| Rear Suspension | : | Showa rear suspension unit, manual preload and rebound damping adjustment |
| Rear Wheel Travel | : | 230 mm / 9.0 in |
| Front Brakes | : | 2 x 320mm floating discs, Brembo Stylema 4 piston Monobloc calipers. Radial front master cylinder |
| Rear Brakes | : | Single 255mm disc, Brembo single piston sliding caliper |
| ABS System | : | Multimode, Optimised Cornering ABS |
| Wheels | : | Spoked Tubeless |
| Front Wheel | : | 21 x 2.15 in |
| Rear Wheel | : | 17 x 4.25 in |
| Front Tyre | : | 90/90-21 |
| Rear Tyre | : | 150/70R17 |
| Rake | : | 24.4┬░ |
| Trail | : | 145.8 mm / 5.74 in |
| Dimensions | : | Width   935 mm / 36.8 in Height  1452 - 1502 mm / 57.1 - 59.1 in |
| Wheelbase | : | 1551 mm / 61.06 in |
| Seat Height | : | 860 - 880 mm / 33.9 - 34.6 in |
| Dry Weight | : | 201 kg / 443.1 lbs |
| Fuel Capacity | : | 20 Litres / 5.28 US gal |
