INFO MOTOR
| Make Model | : | Kawasaki Z-X10RR Ninja |
|---|---|---|
| Year | : | 2024 |
| Engine | : | Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder |
| Capacity | : | 998 cc / 60.9 cu-in |
| Bore x Stroke | : | 76.0 x 55.0 mm |
| Compression Ratio | : | 13.0:1 |
| Cooling System | : | Liquid cooled |
| Lubrication | : | Forced lubrication, wet sump with oil cooler |
| Induction | : | DFI with 47mm Mikuni throttle bodies (4) and Variable Air Intake System (VAI) |
| Ignition | : | TCBI with digital advance and Sport-Kawasaki Traction Control (S-KTRC) |
| Starting | : | Electric |
| Max Power | : | 150 kW / 204 hp @ 14000 rpm |
| Max Power Ram Air | : | 157.5 kW / 214 hp @ 14000 rpm |
| Max Torque | : | 111.8 Nm / 82.4 lb-ft @ 11700 rpm |
| Clutch | : | Wet multi-disc, manual |
| Transmission | : | 6-speed, return, cassette |
| Final Drive | : | Sealed Chain |
| Primary Reduction Ratio | : | 1.681 (79/47) |
| Gear Ratio | : | 1st 2.600 (39/15) 2nd 2.158 (41/19) 3rd 1.882 (32/17) 4th 1.650 (33/20) 5th 1.476 (31/21) 6th 1.304 (30/23) |
| Final Reduction Ratio | : | 2.294 (39/17) |
| Frame | : | Aluminum perimeter |
| Front Suspension | : | 43mm inverted Balance Free Fork, adjustable stepless rebound and compression damping, spring preload adjustability, and top-out springs |
| Front Wheel Travel | : | 120 mm / 4.7 in |
| Rear Suspension | : | Horizontal back-link with Balance Free gascharged shock, stepless, dual-range (low-/highspeed) compression damping, stepless rebound damping, fully adjustable spring preload |
| Rear Wheel Travel | : | 115 mm / 4.5 in |
| Front Brakes | : | 2x 330 mm Intelligent Braking (KIBS), Brembo® dual semifloating discs with dual radial mounted monobloc 4-piston calipers |
| Rear Brakes | : | Single 220mm disc KIBS-supported with aluminum single-piston caliper |
| Front Tyre | : | 120/70 ZR17 |
| Rear Tyre | : | 190/55 ZR17 |
| Rake | : | 25┬░ |
| Trail | : | 105 mm / 4.2 in |
| Dimensions | : | Length  2085 mm / 82.1 in Width     750 mm / 29.5 in Height  1185 mm / 46.7 in |
| Wheelbase | : | 1450 mm / 57.1 in |
| Ground Clearance | : | 135 mm / 5.3 in |
| Seat Height | : | 835 mm / 32.9 in |
| Wet Weight | : | 207 kg / 456.4 lbs |
| Fuel Capacity | : | 17 Litres / 4.5 US gal |
| Electronic Rider Aids | : | Öhlins® Electronic Steering Damper, Kawasaki Launch Control Mode (KLCM), Kawasaki Intelligent anti-lock Brake System (KIBS), Kawasaki Sport Traction Control (S-KTRC), Kawasaki Engine Braking Control, Kawasaki Quick Shifter (KQS) (upshift & downshift), Kawasaki Corner Management Function (KCMF), Power Modes (Full/Mid/Low) |
